APPLICATIONS
Mobility, rapid deployment, protection against harsh environment Plug-and-Play RO unit for remote worker camps, mining, Oil & Gas operators, remote Power plants, large-scale construction projects, bunkering services, emergency municipal and military water supply
A stable company with extensive experience in the water industry.
We develop high-quality products at competitive prices.
Delivering advanced solutions backed by knowledge, innovation, and industry expertise.
EQUIPMENT
• EBARA high pressure pump EVMS5 14N5 1 pcs
• 8040-1 membrane housing 2 pcs
• BB20 sediment prefilter 2 pcs
• Motorized valves 1 pcs
• Balancing valves 2 pcs
(concentrate reject, concentrate recycle)
• Electrical panel with UnitronicsPLC controller 1 set
• ABB conductivity controller 1 set (pH option)
• Danfoss pressure switches 2 pcs
• AISI 316 Stainless-steel high-pressure line 1 set
• AISI 304 Stainless steel frame 1 set
• Grundfos dosing pump 1 set (option for 2 sets)
• FRP Vessel 1865 (MMF/ACF/IEU) 2 pcs
• Automatic filter control valves 2 pcs
• CIP Tank 300L
• Permeate Storage Tank 2000L
• EBARA low pressure pump Matrix 3-5T
PHYSICAL PARAMETERS:
Approximate dimensions (bare) 6.0 ×2.4 ×2.6 m
Approximate dimensions (crated) 6.0 ×2.4 ×2.6 m
(Width ×Depth ×Height, ±5%)
Approximate weight (bare) 2590 kg
Approximate weight (crated) 2700 kg
Maximum Power Consumption 4 650 W
CONNECTIONPORTSIZES:
Inlet water G 1¼″
Permeate G 1″
Concentrate G ¾″
CIPinletG1¼″
CIP return G 1¼″
CIP permeate G 1″
Antiscalant dosing port G ½″
