APPLICATIONS
Desalination units for operations requiring a reliable source of fresh water: boutique coastal hotels, eco-resorts, coastal farms, greenhouses, coastal construction site, small islands, science coastal camps
A stable company with extensive experience in the water industry.
We develop high-quality products at competitive prices.
Delivering advanced solutions backed by knowledge, innovation, and industry expertise.
PHYSICAL PARAMETERS:
Approximate dimensions (bare) 2.1 ×1.0 ×1.90 m
Approximate dimensions (crated) 2.30 ×1.20 ×2.0 m
(Width ×Depth ×Height, ±5%)
Approximate weight (bare) 350 kg
Approximate weight (crated) 460 kg
Maximum Power Consumption 11 530 W
EQUIPMENT
• Danfosshigh pressure pump APP 5.1 1 pcs
• 8040-2 membrane housing 2 pcs
• BB20 sediment prefilter 3 pcs
• Motorized valves 1 pcs
• Balancing valve (concentrate reject) 1 pcs
• Pulsation Dampener 1 pcs
• Electrical panel with PLC Unitronicscontroller 1 set
• ABB conductivity controller 1 set (pH option)
• Danfoss pressure switches 2 pcs
• AISI 316 Stainless-steel high-pressure line 1 set
• AISI 304 Stainless steel frame 1 set
• Grundfos dosing pump 1 set (option for 2 sets)
CONNECTION PORT SIZES:
Inlet water G 1½″
Permeate G 1½″
Concentrate G 1″
CIP inlet G 1½″
CIP return G 1½″
CIP permeate G 1½″
Antiscalant dosing port G ½″
